H83FFDSH

H83FFDSH is a 24-channel G.fast service board without a built-in splitter. It is used for access of G.fast services and supports vectoring and metallic line testing (MELT) functions.

Functions and Specifications

For details, see "Differences Between G.fast Service Boards".

Board Power Consumption

For details, see "Board Power Consumption".

Working Principle

Figure 1 illustrates the working principle of the H83FFDSH board.

Figure 1 Working principle of the H83FFDSH board

The basic working principle of the H83FFDSH board is as follows:

  • The switch module switches the backplane port to the chipset module port.

  • The chipset module implements functions such as amplification, filtering, analog-to-digital (A/D) and digital-to-analog (D/A) conversion, coding/decoding, and encapsulation/decapsulation for the signals.

  • The protection module protects and isolates the board from lightning strikes.

  • The control module decodes and monitors signals.

  • The power module supplies power to other function modules of the board.

  • The clock module provides the working clock signals for other function modules of the board.

The centralized vectoring processing board processes vectoring signals and provides a 10G-KR port to connect to the H83FFDSH board.

Ports on the Front Panel



Indicator

Silk Screen

Name

Color

Status

Meaning

RUN ALM

Operating status indicator

Green

On

The board operates normally.

Red

On

The board is faulty.

Pin Assignment

Table 1 shows the pin assignment of the xDSL port on the front panel of the H83FFDSH board.

Pin

Signal

Pin

Signal

Port

Pin

Signal

Pin

Signal

Table 1 Pin assignments of the xDSL port

Pin

Signal

Pin

Signal

Port

Pin

Signal

Pin

Signal

64

15

48

7

32

16

16

-

63

47

31

15

62

14

46

6

30

17

14

-

61

45

29

13

60

13

44

5

28

18

12

-

59

43

27

11

58

12

42

4

26

19

10

-

57

41

25

9

56

11

40

3

24

20

8

-

55

39

23

7

54

10

38

2

22

21

6

-

53

37

21

5

52

9

36

1

20

22

4

-

51

35

19

3

50

8

34

0

18

23

2

-

49

33

17

1
