1. Integrate fiber and copper lines in one box, support smooth evolution
2. the embedded hardware encryption technique
3. Support stateful firewall and rich VPN technologies
Specifications | AR100 Series | AR120 Series | AR200 Series | AR160 Series |
WAN Speed with Services* | 40 Mbit/s | 50 Mbit/s | 150 Mbit/s | 150 Mbit/s; 600 Mbit/s |
Number of Recommended Users | 20 | 20 | 50 | 50 |
Fixed WAN Ports | 1 x GE, 1 x VDSL2 (compatible with ADSL2+ Annex A/M, Annex B/J; support vectoring) | 1 x FE or 1 x GE | 1 x FE AR207: 1 x ADSL2 + Annex A/M | 1 x GE or 1 x GE Combo AR168: 1 x G.SHDSL AR169: 1 x VDSL2 AR169EW/AR169EGW-L: 1 x VDSL2 over POTS with Bonding (support dying gasp and vectoring) |
Fixed Ethernet Switching Ports | 4 x GE (can be configured as WAN interfaces) | 4 x FE or 4 x GE (can be configured as WAN interfaces) | 8 x FE (can be configured as WAN interfaces) | 4 x GE (can be configured as WAN interfaces) |
Fixed Voice Ports | - | AR129CV/AR129CVW/AR129CGVW-L: 2 x FXS | - | 4 x FXS, 1 x FXO (voice model) |
Integrated 3G/LTE | AR109GW-L: FDD LTE | AR129CGVW-L: FDD LTE | WCDMA HSPA+7 (3G model) | FDD LTE (LTE model) |
Wi-Fi | 802.11b/g/n | 802.11b/g/n AR129CGVW-L: 802.11ac, 802.11b/g/n (Wi-Fi model) | 802.11b/g/n (Wi-Fi model) | 802.11b/g/n or 802.11a/b/g/n/ac/ac wave 2, 4 x 4:4 MU-MIMO (Wi-Fi model) |
Memory | 256 MB | 256 MB | 512 MB | 512 MB or 1 GB |
Flash | 256 MB | 256 MB | 512 MB | 512 MB |
Dimensions (W x D x H ) | 230 mm x 130 mm x 30 mm | 300 mm x 216.4 mm x 44 mm 230 mm x 130 mm x 30 mm | 300 mm x 216.4 mm x 44 mm | 300 mm x 216.4 mm x 44 mm 270 mm x 155 mm x 30 mm |
View Full Specs | AR100, AR120 and AR200 | AR160 |
*Service performance depending on specific feature configuration
