ES3600C V5 800GB NVMe

Part #: 02312JVL

Module #: HICASPWDD

Price: US$ 962.64

Availability: In Stock

* Ship and Warranty by Huawei USA CANADA.
* Price includes USA customs duty and shipping cost.
* Online Price may be wrong or outdated and can NOT be used as proof by anyone or any organization for any purpose.

The ES3000 V5 NVMe SSD card is a half-height half-length, high-performance PCIe SSD that uses Huawei’s Hi1812e SSD controller chip, provides 4 x PCIe 3.0 interfaces, and complies with the NVMe 1.3 standard. It is installed in the PCIe slot of the server and supports performance upgrade of the current server to boost the performance of applications, such as database, cloud service, virtualization, distributed storage, and big data, and help customers reduce system TCO.



ModelES3600C V5
Form FactorHHHL PCIe card
InterfacePCIe 3.0 x4
NVMe ProtocolNVMe 1.3
NAND Flash3D TLC
Usable Capacity800 GB, 1.6 TB, 3.2 TB, and 6.4 TB
Sequential
Read/Write
Bandwidth @ 1 MB
800 GB: 3,500/1,000 MB/s
1.6 TB: 3,500/1,900 MB/s
3.2 TB: 3,500/3,200 MB/s
6.4 TB: 3,500/3,050 MB/s
Random Read/
Write IOPS @ 4 KB
800 GB: 420k/115k
1.6 TB: 740k/195k
3.2 TB: 825k/300k
6.4 TB: 825k/250k
Average Read/Write
Latency @ 4 KB
800 GB: 96 μs/15 μs
1.6 TB: 96 μs/14 μs
3.2 TB: 96 μs/14 μs
6.4 TB: 88 μs/15 μs
Power
Consumption
5W (idle)
21W (maximum)
Endurance (see note 1)3 DWPD for 5 years
Maximum Data Written (see note 2)800 GB: 4.38 PBW
1.6 TB: 8.76 PBW
3.2 TB: 17.52 PBW
6.4 TB: 35.04 PBW
Weight< 182g
TRIMSupported
ReliabilityMTBF: 2.5 million hours
AFR: ≤0.35%
UBER: 10-18
TemperatureNon-operational: -40ºC to +70ºC
Operational: 0ºC to 70ºC (U.2)
Data Retention
(power off)
3 months at 40ºC (104ºF)
Supported ServersServers supporting PCIe SSD Card
CertificationsChina: RoHS
Europe: WEEE, RoHS, REACH, and CE
America: FCC, NRTL, and IC
Japan: VCCI
Australia: RCM
Saudi Arabia: KSA
Kuwait: KUCAS
Nigeria: SONCAP
Uganda: UNBS
Notes:
Note 1: Endurance DWPD: Disk Writes per Day.
Note 2: Maximum Data Written PBW: Petabyte Writes
