ES3500S V5 960GB SAS

Part #: 02312EYL

Module #: HIDASSBAI

Price: US$ 800.77

Availability: In Stock

* Ship and Warranty by Huawei USA CANADA.
* Price includes USA customs duty and shipping cost.
* Online Price may be wrong or outdated and can NOT be used as proof by anyone or any organization for any purpose.

3D TLC ES3500S V5 960G 1920G 3840G 7680G 15360G Read Intensive SAS SSD

12GB SAS 2200M bandwidth 430K IOPS



ES3500S V5 Models


02312EYLHIDASSBAIES3500S   V5 SSD 960GB SAS 12G 12Gb/s Read Intensive 2.5 inch,HWE52SS3960L002N
02312EYMHIDASSBAJES3500S   V5 SSD 1920GB SAS 12G 12Gb/s Read Intensive 2.5 inch,HWE52SS31T9L002N
02312EYNHIDASSBAKES3500S   V5 SSD 3840GB SAS 12G 12Gb/s Read Intensive 2.5 inch,HWE52SS33T8L002N
02312EYPHIDASSBALES3500S   V5 SSD 7680GB SAS 12G 12Gb/s Read Intensive 2.5 inch,HWE52SS37T6L002N
02312GDBHIDASSBAQES3500S   V5 SSD 15360GB SAS 12G 12Gb/s Read Intensive 2.5 inch,HWE52SS315TL002N


ES3500S ES3600S V5 SAS SSD Specifications

ModelES3500S V5ES3600S V5
Form Factor2.5-inch2.5-inch
InterfaceSAS 3.0 12 Gbit/sSAS 3.0 12 Gbit/s
NAND Flash3D TLC3D TLC
Usable Capacity960 GB, 1.92 TB, 3.84 TB, 7.68 TB, and 15.36 TB800 GB, 1.6 TB, 3.2 TB, and 6.4 TB
Sequential Read/Write Bandwidth @ 1 MB960 GB: 2,200/900 MB/s
1.92 TB: 2,200/1800 MB/s
3.84 TB: 2,200/2000 MB/s
7.68 TB: 2,200/1750 MB/s
15.36 TB: 2,200/1600 MB/s		800 GB: 2,200/1,000 MB/s
1.6 TB: 2,200/1,800 MB/s
3.2 TB: 2,200/2,000 MB/s
6.4 TB: 2,200/1,750 MB/s
Random Read/Write IOPS @ 4KB960 GB: 335k/38k
1.92 TB: 425k/75k
3.84 TB: 430k/108k
7.68 TB: 430k/80k
15.36 TB: 420k/75k		800 GB: 365k/113k
1.6 TB: 425k/155k
3.2 TB: 430k/155k
6.4 TB: 430k/155k
Average Read/Write Latency @ 4 KB118 μs/38 μs118 μs/38 μs
Power
Consumption		4W to 15W4W to 15W
Endurance (see note 1)1 DWPD for 5 years3 DWPD for 5 years
Maximum Data Written (see note 2)960 GB: 1.752 PBW
1.92 TB: 3.504 PBW
3.84 TB: 7.008 PBW
7.68 TB: 14.016 PBW
15.36 TB: 28.032 PBW		800 GB: 4.38 PBW
1.6 TB: 8.76 PBW
3.2 TB: 17.52 PBW
6.4 TB: 35.04 PBW
Weight< 182g< 182g
ReliabilityMTBF: 2.5 million hours
AFR: ≤ 0.35%
UBER:10E-18		MTBF: 2.5 million hours
AFR: ≤ 0.35%
UBER:10E-18
TemperatureNon-operational: -40°C to +85°C
Operational: 0°C to 60°C		Non-operational: -40°C to +85°C
Operational: 0°C to 60°C
Notes:
Note 1: Endurance DWPD: Disk Writes per Day.
Note 2: Maximum Data Written PBW: Petabyte Writes
Note 3: The above is an SAS dual-port performance
