Focus on Americas Market

ES3500P V5 1TB NVMe

Part #: 02312EYA

Module #: HIDASPBAA

Price: US$ 244.12

Availability: In Stock

* Ship and Warranty by Huawei USA CANADA.
* Price includes USA customs duty and shipping cost.
* Online Price may be wrong or outdated and can NOT be used as proof by anyone or any organization for any purpose.

3D TLC ES3500P 1T 2T 4T 8T NVMe PCIe SSD

14us Latency 3.5G bandwidth 825K IOPS


ES3500P V5 Models
02312EYAHIDASPBAAES3500P   V5 SSD,1000GB,NVMe PCIe,Read Intensive,2.5inch,HWE52P431T0L002N
02312EYBHIDASPBABES3500P   V5 SSD,2000GB,NVMe PCIe,Read Intensive,2.5inch,HWE52P432T0L002N
02312EYDHIDASPBACES3500P   V5 SSD,4000GB,NVMe PCIe,Read Intensive,2.5inch,HWE52P434T0L002N
02312EYFHIDASPBADES3500P   V5 SSD,8000GB,NVMe PCIe,Read Intensive,2.5inch,HWE52P438T0L002N


ES3500P ES3600P V5 NVMe SSD Specifications

ModelES3500P V5ES3600P V5
Form FactorU.2U.2
Interfaces4 x PCIe 3.04 x PCIe 3.0
NVMe ProtocolNVMe 1.3NVMe 1.3
NAND Flash3D TLC3D TLC
Usable Capacity1 TB, 2 TB, 4 TB, and 8 TB800 GB, 1.6 TB, 3.2 TB, and 6.4 TB
Sequential
Read/Write
Bandwidth @ 1 MB
1 TB: 3,500/1,000 MB/s
2 TB: 3,500/1,900 MB/s
4 TB: 3,500/3,200 MB/s
8 TB: 3,500/2,600 MB/s
800 GB: 3,500/1,000 MB/s
1.6 TB: 3,500/1,900 MB/s
3.2 TB: 3,500/3,200 MB/s
6.4 TB: 3,500/3,050 MB/s
Random Read/
Write IOPS @ 4 KB
1 TB: 420k/63k
2 TB: 740k/90k
4 TB: 825k/110k
8 TB: 825k/150k
800 GB: 420k/115k
1.6 TB: 740k/195k
3.2 TB: 825k/300k
6.4 TB: 825k/250k
Average Read/Write
Latency @ 4 KB
88 μs/14 μs88 μs/14 μs
Power
Consumption
5W (idle)
21W (max)
5W (idle)
21W (max)
Endurance (note 1)1 DWPD for 5 years3 DWPD for 5 years
Maximum Data Written (note 2)1 TB: 1.825 PBW
2 TB: 3.65 PBW
4 TB: 7.3 PBW
8 TB: 14.6 PBW
800 GB: 4.38 PBW
1.6 TB: 8.76 PBW
3.2 TB: 17.52 PBW
6.4 TB: 35.04 PBW
Weight< 182g< 182g
TRIMSupportedSupported
ReliabilityMTBF: 2.5 million hours
AFR: ≤ 0.35%
UBER:10E-18
MTBF: 2.5 million hours
AFR: ≤ 0.35%
UBER:10E-18
TemperatureNon-operational: -40ºC to +70ºC
Operational: 0ºC to 70ºC (U.2)
Non-operational: -40ºC to +70ºC
Operational: 0ºC to 70ºC (U.2)
Data Retention
(power off)
3 months at 40ºC (104ºF)3 months at 40ºC (104ºF)
Supported ServersServers supporting NVMe PCIe SSD disksServers supporting NVMe PCIe SSD disks
CertificationsChina: RoHS
Europe: WEEE, RoHS, REACH, and CE
America: FCC, NRTL, and IC
Japan: VCCI
Australia: RCM
Saudi Arabia: KSA
Kuwait: KUCAS
Nigeria: SONCAP
Uganda: UNBS
China: RoHS
Europe: WEEE, RoHS, REACH, and CE
America: FCC, NRTL, and IC
Japan: VCCI
Australia: RCM
Saudi Arabia: KSA
Kuwait: KUCAS
Nigeria: SONCAP
Uganda: UNBS
Notes:
Note 1: Endurance DWPD: Disk Writes per Day.
Note 2: Maximum Data Written PBW: Petabyte Writes
