Rated 380, 400, and 415 V AC with 25, 50, 60 kVA Power Capacity
| Model | UPS5000-E-75k-SM (1m high cabinet) | UPS5000-E-125k-FM (2m high cabinet) | UPS5000-E-(50-800k)-SM/FM (50K Module) | UPS5000-E-(400-600k)-SMS/FMS (60K Module) |
| Power Module Capacity | 25 kVA/25 kW | 50 kVA/50 kW | 60 kVA/54 kW | |
| Rack Capacity | 75 kVA rack (max support 3+1 power modules) | 125 kVA rack (max support 5+1 power modules) | 200, 300, 400, 500, 600, and 800 kVA rack (supports 4, 6, 8, 10, 12, 16 power modules, respectively) | 400, 500, and 600 kVA rack (supports 7, 9, and 10 power modules, respectively) |
| Hot-swap Modules | Power module, bypass module, and energy control module | |||
| Input and Output Systems | 3Ph + N + PE | 3Ph + N + PE | 3Ph + N + PE | 3Ph + N + PE |
| Rated Voltage | 380, 400, and 415 V AC | 380, 400, and 415 V AC | 380, 400, and 415 V AC | 380, 400, and 415 V AC |
| Output Power Factor | 1 | |||
| Communications | Modbus, SNMP, and dry contact | |||
