Huawei NetEngine Series Core Router

Highest performance routers to power innovative enterprise applications from small to super huge scale. Carrier-grade reliability, flexible modular architecture, and energy-efficient technologies add up to great service at lowest TCO.



NE05E/08E Series Mid-range Service Routers

NE05E

Comprehensive features in compact, energy-efficient routers optimized for resilient cloud-based services and Provider Edge (PE) applications



NE08E-S6

NE05E-S2

NE05E-SE/SF

NE05E-SG/SH/SI

NE05E-SJ/SK/SL/SM

Forwarding Capacity

(IPv4/IPv6)

84 Mpps

18 Mpps

66 Mpps

18 Mpps

SJ/SK/SL: 9 Mpps

SM: 6 Mpps

Forwarding Capability (IMIX)

112 Gbit/s

 24 Gbit/s

88 Gbit/s

24 Gbit/s

SJ/SK/SL: 12 Gbit/s

SM: 8 Gbit/s



NetEngine20E-S Series Universal Service Routers

NE20E-appearance

High-performance, mid-range routing platform supporting IP/MPLS-based services for high-bandwidth access, aggregation, and edge routing between networks; energy-efficient design and cooling technology allows high-density configuration and reduces TCO

Item

NE20E-S2E

NE20E-S2F

NE20E-S4

NE20E-S8

NE20E-S16

Switching Capacity

160 Gbit/s

320 Gbit/s

480 Gbit/s

480 Gbit/s

480 Gbit/s

Forwarding Performance

70 Mpps

150 Mpps

180 Mpps

360 Mpps

360 Mpps

Fixed Ports

2 x 10 GE

(SFP+) and 24 x

GE (SFP)

4 x 10 GE

(SFP+) and 40 x

GE (SFP)

-

-

-

Number of Slots

2 PICs

2 PICs

2 MPUs

1 NSP

4 PICs

2 MPUs

2 NSPs

8 PICs

2 MPUs

2 NSPs

16 PICs



NetEngine40E Series Universal Service Routers

NE40E-appearance

Meet high bandwidth requirements in IP backbone networks, IDCs, and large enterprise networks; 480 GE line cards configurable to 10 GE and 100 GE ports provide resilient access in converged WANs and MANs; comprehensive QoS, user management, and accounting features

Attribute

NE40E-X16

NE40E-X8

NE40E-X3

Switching Capacity

12.58 Tbit/s

7.08 Tbit/s

1.08 Tbit/s

Forwarding Performance

5,760 Mpps

2,880 Mpps

540 Mpps

MPU Slots

2

2

2

SFU Slots

4

1

0

LPU Slots

16

8

3

Service Card Slots

Maximum 48

Maximum 32

Maximum 12



NetEngine5000E Cluster Routers

NE5000E-appearance

Huge capacity cluster routers for Internet backbone, metropolitan core, ISPs, and large enterprise networks; unique, back-to-back clustering option, energy-efficient technologies, and carrier-grade reliability ensure a robust, 100 GE routing platform

Specifications

NE5000E

Throughput

Non-blocking switch fabric, multi-chassis support

Maximum system capacity:

819 Tbit/s, 64 chassis (400G)

Port Capacity

15 Tbit/s, single chassis (480G)

Slots/CLC

16 slots/single chassis



Vendor Mapping

  Huawei Cisco Juniper Alcatel-Lucent ZTE HP Ericsson
Core Router NE5000E-X16A NCS6000   7950 ZXR10 T8000
NE5000E-X16 CRS-X/-3/-1 T4000/T1600
High End
Router
NE40E-X16A ASR9922 MX2020 7750 SR-12e ZXR10 M6000-18S
NE40E-X8A ASR9912 MX2010
NE40E-X16 ASR9010   7750 SR-12 ZXR10 M6000-16 HP8812 SSR8020
NE40E-X8 ASR9006 MX960 7750 SR-7 ZXR10 M6000-8/M6000-8S/M6000-5S HP8808 SSR8010
NE40E-X3/X3A ASR9904 MX480/MX240   M6000-3S HP8805 SSR8004
Midddle End
Router
NE20E-S16 ASR1013   7750 SR-c12   HP6808
  ASR1009-X   7750 SR-A8 ZXR10 M6000-2S10 HP6804
NE20E-S8 ASR1006-X   ZXR10 M6000-2S4 HP6802
ASR1006 MX104 7750 SR-A4 ZXR10 6812
NE20E-S4 ASR1004 7750 SR-c4 ZXR10 6804
NE20E-S2F ASR9001 MX80/40 7710 SR ZXR10 6802
NE20E-S2E ASR1002     HP6602-XG
NE08E/NE05E ASR1001-X MX10   ZXR10 GER08/04/02 HP6602-G
BRAS   ASR9900 MX2000
ME60-X/NE40E-X ASR9000 MX960/480/240 7750 SR M6000-S/M6000   SSR8000
  ASR1000 MX104       SE1200/800 (Old)
    MX80/40

Get Started


Quote on Huawei NE05E Core router
Quote on Huawei NE08E Core router
Quote on Huawei NE20E-S16 Core router
Quote on Huawei NE20E-S2E Core router
Quote on Huawei NE20E-S2F Core router
Quote on Huawei NE20E-S4 Core router
Quote on Huawei NE20E-S8 Core router
Quote on Huawei NE40E Core router
Quote on Huawei NE40E-X16 Core router
Quote on Huawei NE40E-X16A Core router
Quote on Huawei NE40E-X3 Core router
Quote on Huawei NE40E-X3A Core router
Quote on Huawei NE40E-X8 Core router
Quote on Huawei NE40E-X8A Core router
Quote on Huawei NE5000E-X16 Core router
Quote on Huawei NE5000E-X16A Core router

Contact us:     Tel: 1-866-318-6636
                      Email: info@actfornet.com



Huawei Core Router

The NE Series router is the high-end router for the telecom data communication networks. It can be deployed as a P/PE router in the IP core and metro networks, and helps operators to accommodate the rapid increase of network bandwidth.
