Dimensions (H x W x D)(mm):442x220x43.6
Number of slots for service boards:2
Product capacity:PKT:120G, TDM:30G HO,5G LO
Maximum rate per channel:10Gbit/s(OTU2)
Mounting option:19-inch cabinet,ETSI cabinet
Standard working voltage:-48 V/-60 V DC power input
Specifications | OSN 1800 I | OSN 1800 I Enhanced | OSN 1800 II | OSN 1800 II Enhanced | OSN 1800 V |
Dimensions (H x W x D) | 44 mm x 442 mm x 220 mm | 44 mm x 442 mm x 220 mm | 88 mm x 442 mm x 220 mm | 88 mm x 442 mm x 220 mm | 221 mm x 442 mm x 224 mm |
Number of Service Slots | 3 slots per cabinet (DC) 1 slots per cabinet (AC) | 2 slots per cabinet (DC) 1 slots per cabinet (AC) | 7 slots per cabinet (DC) 5 slots per cabinet (AC) | 6 slots per cabinet (DC) | 15 slots per cabinet (DC) 12 slots per cabinet (AC) |
Cross-connect Capability | N/A | OTN: 40G ODUk (k=0/1/2/2e/flex) Packet: 120G SDH: 40G (high-order), 5G (low-order) | N/A | OTN: 200G ODUk (k=0/1/2/2e/flex) Packet: 160G SDH: 50G (high-order), 20G (low-order) | OTN: 700G ODUk (k=0/1/2/2e/flex Packet: 700G SDH: 280G (high-order), 40G (low-order) |
Number of Wavelengths (maximum) |
| ||||
Rate per Wavelength (maximum) | 100G/200G | ||||
Installation Rack | 19-inch to 23-inch rack, ETSI 300 mm or 600 mm rack | ||||
Power Supply | 110V to 220V AC, -48V to -60V DC |
