The iMaster NCE-IP, a core component of the Huawei IP WAN solution, enables cloud-based WAN solutions to maximize the value of networks. The iMaster NCE-IP has strong and flexible management capabilities that allow the rapid deployment and provisioning of VPN services on WANs. It can automate the monitoring, planning, and adjustment of network traffic based on set constraints, which improves network resource utilization. In addition, it provides differentiated SLA guarantees, makes network resources manageable and visualized, and greatly increases the efficiency of O&M. The iMaster NCE-IP uses an open architecture to support basic network services and northbound standardization and enables network northbound openness to reduce the difficulty of interconnection. It also provides customers with a ROADS experience.

Specifications

ItemsFeatures
IP/MPLS Connectivity AutomationAutomated provisioning of VPN private line services
Bandwidth on demand (BoD) and bandwidth calendaring
L3VPN service discovery and tunnel discovery
Resource VisualizationPhysical and logical topology
Tunnel topology
VPN service topology
VPN service path and status
Link, tunnel, and VPN connectivity checking
Network OptimizationMPLS network optimization:
Global path computation and optimization and single service path optimization for MPLS tunnels
PCE for RSVP-TE/SR-TE
Innovative ROAM algorithm for accurate path computation based on latency, bandwidth, etc.
IP network optimization:
Virtual link group addition, modification, and deletion
Inter-AS one-hop optimization based on IP addresses, AS numbers, or community attributes
One-hop or multi-hop IP backbone intra-domain optimization based on IP addresses, AS numbers, or community attributes
Open Northbound APIsNetwork O&M northbound API
Network optimization northbound API
On-demand service provisioning northbound API
High AvailabilityClustering and geographic redundancy
Service data consistency checking
L3VPN/VLL Service Capacity128K
L3VPN/VLL Service Provisioning Time (single)10 seconds per service
L3VPN/VLL Service Provisioning Time (concurrent)5 services per second
SR-TE Tunnel Optimization Capacity64K
RSVP-TE Tunnel Optimization Capacity64K
Single Re-optimization Time of a Large-scale Network8 minutes (2,000 devices and 128K TE LSPs)
Single Re-optimization Time of a Medium-sized Network2 minutes (500 devices and 32K TE LSPs)
