802.11a/b/g/n/ac/ac Wave 2, 2.4G: 2 x 2:2; 5G-1: 2 x 2:2; 5G-2: 4 x 4:4, 3 Gbit/s
Parameters | AP6750-10T |
Dimensions (H x W x D) | 47 x 220 x 220 mm |
Power Input | DC: 12 V ± 10% |
PoE: In compliance with IEEE 802.3at | |
Maximum Power Consumption | 19.3 W (excluding USB input) |
Note: Actual maximum power consumption depends on local laws and regulations. | |
Maximum Number of Users | ≤ 768 |
Note: Actual number of users varies based on the environment. | |
Maximum Transmit Power | 2.4 GHz: 23 dBm (combined power) |
5 GHz-0: 24 dBm (combined power) | |
5 GHz-1: 27 dBm (combined power) | |
Note: Actual transmit power depends on local laws and regulations. | |
Operating Temperature | –10°C to 50°C |
Antenna Type | Adaptive array antennas |
MIMO: Spatial Streams | 2.4G: 2 x 2:2; 5G-1: 2 x 2:2; 5G-2: 4 x 4:4 |
Radio Protocols | 802.11a/b/g/n/ac/ac Wave 2 |
Maximum Rate | 3 Gbit/s |
