AirEngine5762-15HW

Part #: 50084984

Module #: AirEngine5762-15HW

Price: US$ 348

Availability: In Stock

* Online Price may be wrong or outdated and can NOT be used as proof by anyone or any organization for any purpose.


AirEngine 5762-15HW is a Wi-Fi 6 (802.11ax) wall plate Access Point (AP) that supports 2 x 2 Multiple-Input Multiple-Output (MIMO), delivering services on both the 2.4 GHz and 5 GHz bands, achieving a rate of up to 2.975 Gbit/s.

With support for both high bandwidth and high user concurrency — in a notably compact design — the AP features flexible deployment to help reduce investment costs. Such benefits make it purpose-built for Small- and Medium-sized Enterprises (SMEs), hospitals, and cafés.


ParametersAirEngine 5762-15HW
Dimensions (H x W x D)160 x 86 x 45 mm
Power Input

DC: 12 V ±10%

PoE power supply: in compliance with 802.3at/af

Maximum Power Consumption

15 W (excluding USB)

Note: The actual maximum power consumption depends on local laws and regulations.

Maximum Number of Users

≤ 256

Note: The actual maximum number of users varies according to the environment.

Operating Temperature0–40°C
Antenna TypeBuilt-in Smart Antennas
MIMO:Spatial Streams2.4 GHz: 2x2:2; 5 GHz: 2x2:2
Radio Protocols802.11a/b/g/n/ac/ac Wave 2/ax
Maximum Rate2.975 Gbit/s
