Parameters | OptiXstar P622E |
Dimensions (WxDxH) | 160mm x 110mm x 30mm(Without floor mat) |
Weight | <1.5kg |
Operating temperature | -40°C to +55°C |
Operating humidity | 5%RH to 95%RH (non-condensing) |
Power adapter input | 100-240 V AC, 50/60 Hz |
System power supply | 12 V, 1 A |
NNI | Dual GPON |
UNI | 4*GE |
Static powerconsumption | 4W |
Maximum power consumption | 5.5W |
Surge protection specifications | GE: common mode 6 kV; differential mode 1.5 kV. AC power : common mode 6 kV; differential mode 6 kV |
Installation mode | Support outdoor network box installation and indoor desktop installation, wall mounting, or network box installation. |
PON | • Port type: SC/UPC • Complying with ITU-T G.984.2, Class B+ • Receiver sensitivity: -27dBm; • Overload optical power: -8dBm; • Transmission rate: upstream 1.244 Gbit/s, downstream 2.488 Gbit/s • Type B single-homing • Type B dual-homing (supported in Layer 2 forwarding) |
GE | • Port type:RJ-45 • Auto ports speed(10/100/1000 Mbit/s) • Auto-MDI/MDIX • Configuration of the number of MAC addresses learned • VLAN transparent transmission/VLAN filtering |
