Chip platform | HiSilicon Balong750 | HiSilicon Balong750 | HiSilicon Balong750 |
Form | Pair of Outdoor Unit + Indoor Unit | Pair of Outdoor Unit + Indoor Unit | Outdoor Unit + PSU |
Dimensions | Outdoor Unit: 125mm(D) X 275 mm (H) Indoor Unit: 166 mm X 124 mm X 50mm | Outdoor Unit: 125mm(D) X 275 mm (H) Indoor Unit: 166 mm X 124 mm X 50mm | Outdoor Unit: 275mm(H) *125mm(D) PSU BOX: 70.6 mm(L) X 56 mm(W) X 27mm(H) |
Weight | Outdoor Unit: <1.5 kg Indoor Unit: < 290g Total: ~4.2kg | Outdoor Unit: <1.5 kg Indoor Unit: < 290g Total: ~4.2kg | Outdoor Unit: <2 kg PSU adapter + PSU box: <100g Total: ~4.2kg including the packing box and kits |
Water Tightness | Outdoor Unit : IP65 | Outdoor Unit : IP65 | Outdoor Unit : IP65 |
OS | Windows 10, Windows 8.1, Windows 8, Windows 7, Mac OS X 10.9, 10.8, and 10.7 with latest upgrades, Linux | Windows 10, Windows 8.1, Windows 8, Windows 7, Mac OS X 10.9, 10.8, and 10.7 with latest upgrades, Linux | Windows 10, Windows 8.1, Windows 8, Windows 7, Mac OS X 10.9, 10.8, and 10.7 with latest upgrades, Linux, |
Protocol Version | 3GPP Release 10 / 11 /12 | 3GPP Release 10 / 11 /12 | 3GPP Release 10 / 11 /12 |
Operating frequency(LTE) | TDD LTE:B40/B41/B42 FDD LTE:B2/B4/B7/B28 | TDD LTE:B38/B40/B41/B42/B43 FDD LTE:B1/B3/B7/B8/B20 | B2368-A01:B1/B3/B7/B8/B20/B38/B40/B41/B42/B43 B2368-A02:B2/B4/B7/B28/B38/B40/B41/B42/B43 |
Carrier Aggregation | FDD + TDD DL 2CC CA TDD DL 2CC CA / FDD DL 2CC CA TDD UL 2CC CA/ FDD UL 2CC CA | TDD DL 2CC CA / FDD DL 2CC CA FDD + TDD DL 2CC CA / TDD + FDD DL 2CC CA TDD UL 2CC CA / FDD UL 2CC CA FDD + TDD UL 2CC CA / TDD + FDD UL 2CC CA | TDD + FDD CA TDD DL 2CC CA / FDD DL 2CC CA TDD UL 2CC CA/ FDD UL 2CC CA |
Channel Bandwidth | FDD: 5MHz, 10MHz, 15MHz, 20MHz TDD: 10MHz, 15MHz, 20MHz | FDD: 5MHz, 10MHz, 15MHz, 20MHz TDD: 10MHz, 15MHz, 20MHz | FDD: 5MHz, 10MHz, 15MHz, 20MHz TDD: 10MHz, 15MHz, 20MHz |
Tx Power | 23dBm±2.7dB | 23dBm±2.7dB | 23dBm±2.7dB |
Antenna Gain | Band2/Band4/Band7: 3~4dBi Band28: 0~2dBi Band40/Band41: 6~7dBi Band42: 8~9dBi | Band1: 3~4dBi Band3: 4~5dBi Band7/ Band38/Band40/Band41 : 6~7dBi Band8/Band20: 0~2dBi Band42/Band43: 8~9dBi | B2368-A01 3.4G-3.8G(TDD), 8-9dBi 2.3G-2.6G(TDD),6-7dBi; 1.8G-2.6G(FDD), 3-4dBi(Band1); 6-7dBi(Band3/Band7) 700M-900M(FDD), 0-2dBi B2368-A02 3.4G-3.8G(TDD):8-9dBi 1.8G-2.6G:TDD 6-7dBi, FDD 3-4 dBi; 700-900M(FDD):0-2dBi |
MIMO | LTE antenna 1T/4R (TDD) and 1T/2R (FDD) ; | LTE antenna 1T/4R (TDD) and 1T/4R (FDD B3/7),1T/2R(FDD 1/8/20) | LTE antenna 1T/4R (TDD) and 1T/4R (FDD B3/7),1T/2R(FDD 1/8/20) |
LTE Transmission mode | TM2/3/4/7/8/9 | TM2/3/4/7/8/9 | TM2/3/4/7/8/9 |
Interface | Indoor Unit: 3 Ethernet interface (RJ45),10/100/1000 Mbps 1 Giga PSU(Power Supply Unit ) WAN port (RJ45) ,10/100/1000 Mbps 1 POTS interface (RJ11) 1 Power button 1 Reset button 1 WPS button 1 DC IN interface Outdoor Unit: 1 Giga PSU LAN port (RJ45) ,10/100/1000 Mbps 1 USIM card slot (3FF) | Indoor Unit: 3 Ethernet interface (RJ45),10/100/1000 Mbps 1 Giga PSU(Power Supply Unit ) WAN port (RJ45) ,10/100/1000 Mbps 1 POTS interface (RJ11) 1 Power button 1 Reset button 1 WPS button 1 DC IN interface Outdoor Unit: 1 Giga PSU LAN port (RJ45) ,10/100/1000 Mbps 1 USIM card slot (3FF) | Outdoor Unit: 1 Giga PSU LAN port (RJ45) ,10/100/1000 Mbps 1 USIM card slot(3FF,Micro SIM card) Power Supply Unit : 1 PSU WAN port (RJ45) 1 10/100/1000 Mbps Ethernet interface(RJ45) 1 DC IN port |
IP Networking | L2/L3 VPN / three APN / IPV4/IPv4&v6 | L2/L3 VPN / three APN / IPV4/IPv4&v6 | IP pass through |
VoIP | Codec with G.711u-law,G.729,G.711a-law | Codec with G.711u-law,G.729,G.711a-law | - |
Terminal Management | TR069: SNMPv3(SNMPv3 need customization) ;FOTA | TR069: SNMPv3(SNMPv3 need customization); FOTA | TR069,FOTA |
Wi-Fi | 2x2 MIMO 802.11ac/b/g/n, 2.4 GHz & 5GHz Wi-Fi | 2x2 MIMO 802.11ac/b/g/n, 2.4 GHz & 5GHz Wi-Fi |
|
Wi-Fi Encryption | AES,TKIP + AES | AES,TKIP + AES | -
|
