Based on industry standards for video surveillance services, the VCN provides access, forwarding, and Video on Demand (VoD) capabilities. It integrates multiple video surveillance services in one device, such as real-time surveillance, video playback, Pan-Tilt-Zoom (PTZ) controls, alarm linkage, voice intercom, video backup, networking, and forwarding. These services provide a secure, convenient, and practical video surveillance solution for government, transportation, education departments, and enterprises.
| Details | VCN3020 |
| Device Performance | Max. video access channels: Single device: 512 (2 Mbit/s) A maximum of 16 devices can be stacked Max. video forwarding channels: 512 (2 Mbit/s) Max. recording playback channels: 1,024 Mbit/s |
| Platform Performance | Max. connected IPCs: Single domain: 60,000 System: 200,000 Max. disks: 40 (including two independent system disks), hot swap RAID levels: System disk: RAID1, Data disk: RAID5, SafeVideo, and global hot spare |
| Network Management | Network protocols: ONVIF2.4, RTSP, and GB/T 28181 |
| Reliability | Media transmission: Supports adaptive bandwidth, FEC, multicast, and level-by-level media stream forwarding and iPCA Cluster: N+0 cluster that supports dynamic load balancing and fault migration Data safe: Backs up key data in system disks and automatically restores service data in system disks |
| Compatibility | Video formats: H.264, H.265, MJPEG, and SVAC |
| Other | Dimensions (H x W x D): 175 mm x 447 mm x 748 mm Cabinet : Standard 19-inch 4U cabinet Weight: 57 kg (fully configured with HDD) |
