| Vehicle | License plate image enhancement |
| Traffic flow statistics | Motor vehicle/Non-motorized vehicle/Pedestrian |
| Behavior analysis | Fast movement/Tripwire crossing/Intrusion/Area entry or exit/Loitering |
| Crowd flow analysis | Queue length/Head counting/Crowd flow statistics |
| Target | Target detection/Target enhancement/Target attribute recognition |
| Person | Person detection/Personal attribute recognition |
| Non-motorized vehicle | Object classification/Cyclist attributes |
| CPU | Hi3559A V100 |
| Computing power | 4 TOPS |
| Memory | DDR4 4.0 GB |
| Flash type | SPI NAND Flash |
| Max resolution | 4MP 2560(H)*1440(V) |
| Sensor size | 1/1.8" CMOS |
| Min illumination | Color: 0.0004 lux (F1.2, AGC ON, 1/30s shutter speed); B/W: 0.0001 lux (F1.2, AGC ON, 1/30s shutter speed) |
| Focal length | 10-55mm |
| Angle of view | Horizontal: 9.2° (T) to 40.3° (W); vertical: 5.3° (T) to 22.8° (W) |
| Illumination distance | 30m |
| Video encoding format | MJPEG/H.264/H.265 |
| Video frame rate | Configurable (30 fps or 25 fps); default value: 25 fps |
| Audio encoding format | G.711a/G.711u/G.726/OPUS |
| 1 + N | Supported |
| RS-485 port | Supported |
| Boolean port | Supported |
| Ethernet port | Supported |
| Ethernet port quantity | 2 |
| Ethernet port bandwidth | Two RJ45 10M/100M/1000M adaptive Ethernet ports |
| Power type | 24 V AC |
| Power consumption | Maximum: 26.1 W; typical: 8.1 W |
| Operating temperature | –40°C to +60°C (illuminator disabled) –40°C to +40°C (illuminator enabled) |
| Operating humidity | 5% to 95% (non-condensing) |
| IP rating | IP67 |
| IK rating | IK10 |
