Vehicle | License plate image enhancement |
Traffic flow statistics | Motor vehicle/Non-motorized vehicle/Pedestrian |
Behavior analysis | Fast movement/Tripwire crossing/Intrusion/Area entry or exit/Loitering |
Crowd flow analysis | Queue length/Head counting/Crowd flow statistics |
Target | Target detection/Target enhancement/Target attribute recognition/Target recognition |
Person | Person detection/Personal attribute recognition |
Non-motorized vehicle | Object classification/Cyclist attributes |
CPU | Hi3516DV300 |
Computing power | 1 TOPS |
Memory | DDR3 1.0 GB |
Flash type | SPI NAND FLASH |
Max resolution | 4MP 2560(H)*1440(V) |
Sensor size | 1/1.8" CMOS |
Min illumination | Color: 0.005 lux (F1.2, AGC ON, 1/30s shutter speed); B/W: 0.0025 lux (F1.2, AGC ON, 1/30s shutter speed) or 0 lux (infrared illuminator enabled) |
Focal length | 2.8-12mm |
Angle of view | W:102°(Horizontal)*52.0°(Vertical) T:39°(Horizontal)*22°(Vertical) |
IR range | 50m |
Video encoding format | MJPEG/H.264/H.265 |
Video frame rate | Configurable (25 fps or 30 fps) |
Audio encoding format | G.711a/G.711u/G.726/OPUS |
1 + N | Supported |
RS-485 port | Supported |
Boolean port | Supported |
Ethernet port | Supported |
Ethernet port quantity | 1 |
Ethernet port bandwidth | One RJ45 10M/100M adaptive Ethernet port |
Power type | DC12V,PoE(IEEE 802.3at) |
Power consumption | Maximum:10.2W,typical:3.1W |
Operating temperature | –30°C to +55°C (illuminator disabled) –30°C to +40°C (illuminator enabled) |
Operating humidity | 5% to 95%(non-condensing) |
IP rating | IP67 |
IK rating | IK10 (except for the viewing window) |
