Network Management | Supports up to 600,000 cameras in both local and external domains | Supports up to 600,000 cameras in both local and external domains | Supports up to 600,000 cameras in both local and external domains | N/A | N/A | Supports up to 600,000 cameras in both local and external domains |
Video Access | Up to 1024 access channels | Up to 1024 access channels | Up to 1024 access channels | N/A | N/A | Up to 256 access channels |
Up to 2048 Mbit/s access bandwidth | Up to 2048 Mbit/s access bandwidth | Up to 2048 Mbit/s access bandwidth | Up to 512 Mbit/s access bandwidth |
Hard Disk | 40 × 10 TB SATA HDDs | 36 × 10 TB SATA HDDs | 36 × 10 TB SATA HDDs and 2 × 1.80 TB SAS HDDs
| 12 × 4 TB SATA HDDs | 6 × 1.6 TB NVMe disks and 6 × 1.8 TB SAS HDDs | 8 × 10 TB SATA HDDs and 2 × 1.8 TB SAS HDDs
|
RAID Level | Metadata: RAID 1 Video and image data: RAID 5, SafeVideo+
| Metadata: RAID 1 Video and image data: RAID 5, SafeVideo+
| Metadata: RAID 1 Video and image data: RAID 5, SafeVideo+
| Metadata: RAID 1 Video and image data: RAID 5, SafeVideo+
| Metadata: RAID 1 | Metadata: RAID 1 Video and image data: RAID 5, SafeVideo+
|
Analysis | N/A | Video-based facial recognition: 64 channels Image-based facial recognition: 400 channels Video-based personal feature recognition: 64 channels Video-based vehicle recognition: 96 channels | Video-based facial recognition: 64 channels Image-based facial recognition: 400 channels Video-based personal feature recognition: 64 channels Video-based vehicle recognition: 96 channels | License plate recognition (Hong Kong, Macao, Taiwan, and non-Chinese): 21 channels Video search: 42 channels Video synopsis: 42 channels | N/A | Video-based facial recognition: 96 channels Image-based facial recognition: 600 channels Video-based personal feature recognition: 96 channels Video-based vehicle recognition: 144 channels |
Search | N/A | N/A | Face images: 40,000,000 in 3 seconds Full-body images: 400,000 in 3 seconds
| N/A | Face images: 160,000,000 in 3 seconds Full-body images: 6,000,000 in 3 seconds
| Face images: 40,000,000 in 3 seconds Full-body images: 400,000 in 3 seconds
|
Dimensions (H x W x D) | 175 mm x 447 mm x 748 mm | 175 mm x 447 mm x 748 mm
| 175 mm x 447 mm x 748 mm
| 86.1 mm x 447 mm x 748 mm
| 86.1 mm x 447 mm x 748 mm
| 86.1 mm x 447 mm x 748 mm
|
Power Supply
| 100–240 V AC; dual power supplies
| 100–240 V AC; dual power supplies
| 100–240 V AC; dual power supplies
| 100–240 V AC; dual power supplies
| 100–240 V AC; dual power supplies
| 100–240 V AC; dual power supplies
|
Network Interface
| 2 × GE and 2 × 10 GE ports
| 2 × GE and 2 × 10 GE ports
| 2 × GE and 2 × 10 GE ports
| 2 × GE and 2 × 10 GE ports
| 2 × GE and 2 × 10 GE ports
| 2 × GE and 2 × 10 GE ports
|
