Dimensions (H x W x D)

Single-row (with aisle containment):
2410 x 2400 x up to 15,000 mm
2410 x 2300 x up to 15,000 mm
2610 x 2400 x up to 15,000 mm
Dual-row (with aisle containment):
2410 x 3600 x up to 15,000 mm
2410 x 3400 x up to 15,000 mm
2610 x 3600 x up to 15,000 mm

Number of IT Cabinets in a Single Module

Single-row: 2 to 24
Dual-row: 6 to 48

Power Input

208/220 V, 3 phase, 60 Hz
380/400/415 V, 3 phase, 50/60 Hz

IT Power Consumption

208 V: 1–80 kW
380 V: 1–235 kW

Power Density of a Single Cabinet

21 kW/rack

Reliability

Tier II or Tier III (up to Tier IV)

Altitude

Up to 1000 m (derated above 1000 m)

Installation Method

Can be installed directly on a concrete floor or a raised floor
