RH2485 V2 Rack Server

The HUAWEI Tecal RH2485 V2 is a new generation 4-socket rack server in a compact 2U chassis. Powered by Intel® Xeon® E5-4600 v2 series processors, it provides up to 48 computing cores and a memory capacity of 1.5 TB.

Product Features

High Performance, Large Memory, Flexible I/O Expansion

  • Uses Intel® Xeon® E5-4600 v2 series processors and supports 48 DIMMs, providing a memory capacity of up to 1.5 TB. This meets the requirements for various memory-intensive applications.
  • Intel® Xeon® E5-4600 v2 series processors includes 4-, 6-, 8-, 10-, and 12-core options, providing a maximum L3 cache of 30 MB. The Intel® 8 GT/s QuickPath Interconnect (QPI) and Turbo Boost Technology 2.0 ensure powerful computing performance.
  • Flexible PCIe 3.0 slots can accommodate multiple PCIe riser cards, including HUAWEI ES series high-performance PCIe SSD cards, which is the perfect combination of high performance and high I/O bandwidth.

High Energy Efficiency

  • RH2485 V2 complies with ENERGY STAR® standards and the Energy Conservation and Environmentally Friendly Certification released by the China Quality Certification Center. The adoption of 80 PLUS® Platinum PSUs and optimized onboard DC-DC conversion ensure the high power efficiency
  • Multiple temperature sensors monitor the temperatures of key components, accordingly the cooling system can adjust the fan speed precisely to dissipate the heat generated. This increases cooling system efficiency and ensures system stable operation.
  • Dynamic power capping technology controls the maximum power consumption within the preset limit, preventing over-current. Meantime it makes the most use of the power supply.

Simple Management and Maintenance

  • Supports the black box function that facilitates fault location and quickly recovers services.
  • Implements simple system management by using the built-in BMC, which supports SOL and remote KVM, startup, and shutdown.



Product Specification

Item

Tecal RH2485 V2 Rack Server

Form factor

2U rack server

Number of processors

2 or 4

Processor

Intel® Xeon® E5-4600 v2 series
Core options: 4, 6, 8, 10 or 12
Maximum TDP power: 130 W
Maximum frequency:
2.4 GHz (10-core & 12-core)
3.3 GHz (8-core)

2.6 GHz (6-core)
Maximum L3 cache: 30 MB

Memory

48 DDR3 RDIMMs/LRDIMMs, up to 1.5 TB

Internal storage

8 x 2.5" hot-swappable SAS/SATA HDDs or SSDs, up to 8 TB

RAID support

RAID 0, 1, 10, 5, 50, 6, and 60
RAID cache: 512 MB or 1 GB
Power-off protection:
BBU
Supercapacitor

LOM network port

4 on-board GE ports
(Optional) 2 x 10 GE ports

Expansion slot

Up to 8 PCIe 3.0 slots (same for 2 or 4 processors):
1 PCIe 3.0 x 16, for full-height full-length PCIe card
1 PCIe 3.0 x 8, for full-height 3/4-length PCIe card
5 PCIe 3.0 x 8, for half-height half-length PCIe cards
1 PCIe 3.0 x 8, for a RAID mezzanine card

USB port

6 (front: 2, rear: 2, built-in: 2)

Fan module

6 hot-swappable counter-rotating fan modules, N+1 redundant

PSU

2 hot-swappable 1200 W 80 PLUS® Platinum PSUs, 1+1 redundant

Management

Built-in BMC, supporting Huawei USM management software, IPMI, SOL, KVM over IP, and virtual media
One 10/100 Mb/s RJ45 management network port

Operating systems supported

Microsoft Windows Server
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
Oracle Enterprise Linux
Oracle Server VM
Citrix XenServer
Vmware

Power supply

110 V/220 V AC

Operating temperature

5ºC–40ºC

Dimensions

Height: 87.5 mm (3.44 in.)
Width: 447 mm (17.60 in.)
Depth: 740 mm (29.13 in.)

For more details, please refer to Huawei Tecal RH2485 V2 Rack Server Brochure (PDF).

RH2485 V2 Configuration Help

  1. Please select the type of Chassis Module
    2. 1.Include Chassis, main board, etc(Power, DVD, RAID card not included);
    2.Support 8pcs 2.5" HDD at most.
  2. ===CPU===
  3. ===Memory===
  4. ===2.5" Hard Disk===
  5. ===Internal DVD Drive===
  6. ===RAID Card===
  7. ===Mezz Card===
  8. ===PCIe Card===
  9. ===Riser Card===
  10. ===Power Supply===
  11. ===Insert Card===
  12. ===Accessory===
  13. ===Operating System===
  14. ===Value-added service===
