PC-Q25A | ActForNet

MPN: PC-Q25A
Category: Cases >> Booksize (ITX)
Vendor: Lian-Li
Weight: 8.4 LB(S)
Price: US$ 133.45

-
+
Add to Quote
Quote Now
Standard PC components

Standard Mini-ITX motherboard, 3.5-inch / 2.5-inch hard drives, standard ATX PS/2 power supply units. it would be easy to upgrade and server in the future.



Using Standard ATX PS/2 PSU

Standard ATX PS/2 power supply unit with cooling fan, it can be facing the motherboard which are passive cooled.



Thermal Solution

There is a 140mm intake fan input high air flow volume with lower RPM to push the cold air through the HDD cage.



Supports five sata hot swap HDDs

Sata hot swap HDD cage, using thumb screws with rubber suspension, supports five 3.5" HDDs .



Removieable HDDs Rrak

Supports two of 3.5-inch and one of 2.5-inch HDDs, easy installation and services.



When using two or thick,long graphics cards,install 2.5" HDD only.

Model :PC-Q25

Case Type : Mini Tower Chassis

Front bezel Material : Aluminum

Color :Silver

Side Panel : Aluminum

Body Material :Aluminum

5.25" drive bay (External) : None

3.5" drive bay (External) : None

HDD bay : 3.5-Inch HDD x 7 ( Hot swap x 5 ) / 2.5-Inch x3 ( used 3.5-inch bay )

Expansion Slot :2

Motherboard :Mini-ITX / Mini-DTX

System Fan (Front) : 140mm fan x1

System Fan (Top) :120mm fan x1

System Fan (Rear) : None

I/O Ports : None

Maximum Compatibility :
VGA Card length: 320mm
PSU length: 180mm
CPU cooler height: 80mm

Item Dimension (L"xW"xH"):
7.85 x 11.02 x 14.4

Weight:
8.40 lb

Warranty Information
1 Year
