OceanStor S2600T Storage Systems
Employs the RAID 2.0+
technology and provides the widest range of software features among
the comparable products in the industry, helping enterprises resolve
difficulties in data management and maintenance.
Supports heterogeneous virtualization and convergence of SAN and
NAS, helping customers streamline IT systems.
Applies to a wide range of scenarios such as databases, digital
media, Internet operation, backup, disaster recovery, and data
migration.
-
Gives priority to the QoS of mission-critical applications,
automatically balances loads among disks, automatically caches
hotspot data to accelerate access, and implements dynamic
storage tiering, making management and maintenance extremely
simple and intelligent.
-
Converges SAN and NAS and offers compatibility with
heterogeneous storage, helping customers streamline IT systems.
-
Offers higher reliability with the use of RAID 2.0+ that
increases the data reconstruction speed by 20 times compared
with traditional storage.
Item
|
Specifications
|
Cache Capacity per Controller
|
8 GB
|
Front-end Port Types
|
8 Gbit/s Fibre Channel, 16 Gbit/s Fibre Channel, 1
Gbit/s iSCSI, 10 Gbit/s iSCSI (TOE)
|
Back-end Port Types
|
4 x 6 Gbit/s SAS 2.0 wide ports
|
Host Connectivity per Controller
|
6 x 1 Gbit/s iSCSI port + 4 x 8 Gbit/s FC port or 2 x 16
Gbit/s FC port or 4 x 1 Gbit/s iSCSI port or 4 x 10
Gbit/s TOE port
|
Maximum Number of LUNs
|
512
|
Maximum Number of Disks
|
276
|
Supported Disk Types and RAID Levels
|
Disk Types: SAS, NL-SAS, SSD
RAID Levels: 0, 1, 3, 5, 6, 10, 50
|
Software Features
|
HyperSnap (snapshot), HyperCopy (LUN copy), HyperClone
(clone), HyperReplication (remote replication with
support for second-level RPO), HyperMirror (volume
mirror), SmartQoS (intelligent QoS control),
SmartPartition (intelligent partitioning), SmartTier
(intelligent data storage tiering), SmartCache
(intelligent data caching), SmartThin (intelligent thin
provisioning), SmartMotion (intelligent data motion),
SmartMulti-tenant (multi-tenant), SmartMigration (LUN
data migration), SmartErase (LUN data destruction), and
Data Reduction (data volume downsizing)
|
Operating Systems Supported
|
AIX, HP-UX, Solaris, Linux, and Windows
|
NAS Feature
|
Supported
|
Compare and Shop
Vendor |
Product |
Description |
Huawei Advantages |
HUAWEI |
OceanStor S2600T V2 |
OceanStor S2600T Base Configuration |
|
EMC |
VNX5100 |
EMC low-end SAN product |
1.VNX5100 only supports FC, while S2600T supports both FC
and iSCSI.
2.S2600T has higher specification than VNX5100 in cache,
maximum number of disks, maximum number of host ports and so
on. |
EMC |
VNX5300 |
EMC low-end unified storage product |
S2600T has higher specification than VNX5300 in cache,
maximum number of disks and so on. |
HDS |
HUS 110 |
HDS middle-level unified storage product |
S2600T can support larger cache capacity, more disks and
more host ports than HUS 110. |
HP |
P4300 |
HP middle-level SAN product |
1.P4000 only support iSCSI. T series can support FC and
ISCSI.
2.Architecture of P4000 based on server has no
cache-mirroring and low disk space utilization. |
HP |
P4500 |
HP middle-level SAN product |
1.P4000 only support iSCSI. T series can support FC and
ISCSI.
2.Architecture of P4000 based on server has no
cache-mirroring and low disk space utilization. |
IBM |
DS5020 |
IBM middle-level SAN product |
1.S2600T supports more disks and has larger cache capacity
than DS5020.
2.S2600T can support NAS. |
NETAPP |
FAS2240 |
NetApp entry-level unified storage product |
1.S2600T has larger cache capacity and supports more disks
than FAS2240.
2.NetApp storage product only support RAID4 and RAID6. |
NETAPP |
FAS3210 |
NetApp middle-level unified storage product |
1.S2600T has larger cache capacity and supports more disks
than FAS3210.
2.NetApp storage product only support RAID4 and RAID6. |
How to Configure
-
Select the type of C13 AC power cable
-
-
Argentina
-
Australia
-
Brazil
-
Britain
-
Denmark
-
Korea
-
China
-
Europe
-
South
Africa
-
Italy
-
Japan
-
North
America
-
-
Need OceanStor unified storage or not ?
-
When Unified Storage is selected, 2 nodes of file engine is
configured by default.
-
Please choose the type of controller enclosure
configuration(Multi device management please configure the
eSight storage manager)
-
1. Disk enclosures are automatically calculated according to the
principle that disks with different interface cannot be
intermixed in the same disk enclosure.Each S2600T can support 11
disk Enclosures, 3 High-density enclosures or 276 disks at most.
If you need to modify the quantity of disk Enclosure, please
make changes at page 'Bill of Configuration'
2. The OceanStor S2600T and 5500T both have only one pair of SAS
ports that supports high-density disk enclosures.
3. On a high-density enclosure, each pair of SAS ports can be
connected to a maximum of 300 (4 x 75) disks; on a common
enclosure, each pair of SAS ports can be connected to a maximum
of 144 (6 x 24) disks.
4. eSight help: First step: download the eSight data packet;
Second step: input the number of high\Middle\low-end storage
products. If you have any questions can
contact:renxiaoming/90003224
UniSTAR SCT Link:
http://app.huawei.com/unistar/sct/queryProductAction!showProductDetail.action?productId=3684014-
===Disk===
-
4.1 300GB
15K RPM SAS Disk Unit(3.5")
-
Controlled sales: if having the shippment requirement for
3.5inch 15K 300G & 600G SAS HDD Unit, please contact with
xugang/00298325 ahead for shippment requirement apply,
otherwise that could not be ready for the shippmet.
-
4.2 600GB
15K RPM SAS Disk Unit(3.5")
-
Controlled sales: if having the shippment requirement for
3.5inch 15K 300G & 600G SAS HDD Unit, please contact with
xugang/00298325 ahead for shippment requirement apply,
otherwise that could not be ready for the shippmet.
-
4.3 2000GB
7.2K RPM NL SAS Disk Unit(3.5")
-
To ensure the reliability of data,RAID 6 is recommended when
you configure SATA or NL SAS disk.
-
4.4 3000GB
7.2K RPM NL SAS Disk Unit(3.5")
-
To ensure the reliability of data,RAID 6 is recommended when
you configure SATA or NL SAS disk.
-
4.5 4000GB
7.2K RPM NL SAS Disk Unit(3.5")(Recommend)
-
To ensure the reliability of data,RAID 6 is recommended when
you configure SATA or NL SAS disk.
You are advised to configure 4 TB NL-SAS disks in large
capacity scenarios, because they feature better
price/performance ratio than other disks.-
4.6 6000GB
7.2K RPM NL SAS Disk Unit(3.5")(Recommend)
-
To ensure the reliability of data,RAID 6 is recommended when
you configure SATA or NL SAS disk.
-
4.7 2000GB
7.2K RPM NL SAS Disk Unit(3.5",for high-density disk
enclosure)
-
To ensure the reliability of data,RAID 6 is recommended when
you configure NL SAS disk.
-
4.8 4000GB
7.2K RPM NL SAS Disk Unit(3.5",for high-density disk
enclosure)
-
To ensure the reliability of data,RAID 6 is recommended when
you configure NL SAS disk.
-
===Auxiliary Equipment===
-
5.1 Please
choose the Cabinet type
-
The cabinet of 46U is Marketable in these regions: Asia &
Pacific (except for Korea), MENA (except for Egypt and
Israel),and it is controlled in such regions: South Africa,
Latin America, Europe, North America, CIS;no wheels with 46U
Cabinet;
-
5.2 The
Length of Power Cable of Cabinet(m/Cabinet)
-
AC cables from the cabinet to the power distribution frame
in the equipment room: by default, each cabinet is provided
with two cables, which are 20 m in total length
-
5.3 The
Length of Grouding Cable of Cabinet(m/Cabinet)
-
ground cables from the cabinet to the ground bar in the
equipment room: by default, each cabinet is provided with
one cable, which is 5 m in length
-
===Storage Value-added Software===
-
6.1 Need
SnapShot Function or not?
-
OceanStor ReplicationDirector (base version) must be
configured to ensure data consistency of HyperSnap and
achieve periodic snapshot. Huawei OceanStor
ReplicationDirector (base version) is free of charge.
Serving as a piece of disaster recovery management software,
OceanStor ReplicationDirector implements disaster recovery
protection of a wide range of applications including the
Oracle, DB2, Exchange, SQL Server, VMware, FusionSphere, and
NTFS. For details, see its specifications list.
Specifications list link:
http://3ms.huawei.com/mm/docMaintain/mmMaintain.do?method=showMMDetail&f_id=STR15012647000143-
6.2 Need
HyperReplication Function or not?
-
OceanStor ReplicationDirector Base Edition must be
configured to ensure data consistency of HyperReplication
(asynchronous) and achieve periodic data replication. Huawei
OceanStor ReplicationDirector Base Edition is free of
charge.
OceanStor ReplicationDirector (standard edition) is required
if you want to use the functions such as the automatic
disaster recovery protection of storage, disaster recovery
switchover, disaster recovery testing, and topology display.
Serving as a piece of disaster recovery management software,
OceanStor ReplicationDirector implements disaster recovery
protection of a wide range of applications including the
Oracle, DB2, Exchange, SQL Server, VMware, FusionSphere, and
NTFS. For details, see its specifications list.
Specifications list link:
http://3ms.huawei.com/mm/docMaintain/mmMaintain.do?method=showMMDetail&f_id=STR15012647000143-
6.3 Need
SmartVirtualization or not?
-
Please check compatibility list to ensure the third-party
storage device is compatible with HUAWEI storage device.
-
6.4 Need
ReplicationDirector Software Base License or not?
-
OceanStor ReplicationDirector must be installed on an
independent physical server or VM. For details about the
requirements on servers and operating systems, see its
specifications list. Servers and operating systems are
quoted independently or provided by partners.
Specifications list link:
http://3ms.huawei.com/mm/docMaintain/mmMaintain.do?method=showMMDetail&f_id=STR15012647000143
